Past Work

Apex can project manage any size of industrial roofing project. Here you can see just a few examples of contracts that have been completed.

Client: Helston

An overseas customer required one of his UK investments totally refurbished. The old building consisted of a single skin asbestos roof and single skin asbestos vertical gable ends. Apex disposed of the waste via a licensed skip. The vertical gable ends received an over clad system which consisted of 1.6mm galvanized Z rails fixed to the concrete structure followed by 0.7mm gauge vertical cladding sheets. All doors were trimmed with plastisol coated steel corner flashings and drip flashings to the door heads to complete the vertical areas.

Client: Twickenham Stadium

Apex were contracted by the main contractor to assist with the removal of the roof areas to receive the new TV screens prior to hosting the world cup. Once the roof sheets were removed, cranes lifted the huge gantries into position where they were then bolted to the existing steel structure. Once in place, Apex returned to fit new roof sheets and flashings to leave the areas water tight. Contract period: 2 months.

Client: Clevedon

Kingsditch Industrial Estate, Cheltenham

Built up flat roofing system comprising 50mm insulation and a three layer felt system. The pictures show the new raised roof and the lower existing roof of the adjacent building.

Client: Bristol

This is a brick building that needed renovating following a fire. Galvanised steel rails were fixed into brickwork then clad in 0.7mm coated steel sheets in goosewing grey.

Client: Bristol

This new build consisted of a bare portal steel frame. Fixed to this 0.4mm white liner panels followed by 83mm ash grid bar system with 83mm factory clad insulation. The outside was finished with 0.7mm plastic coated steel sheet. The vertical and roof were completed with flashings and fixings. The whole building was fitted with a “Ward” gutter system.

Client: Swindon

These pictures show work completed on two buildings. Each had existing bonded asbestos roofing which needed to be removed. To comply with Health and Safety the whole area was air monitored during the process. The new roofs were then fitted with Kingspan composite panels with 40mm core insulation. Each building had 10% GRP roof lights. The canopy roof was reinstated with 0.7mm plastic coated sheeting. Both building with finished in Goosewing grey with poppy red flashings.

Client: Bristol

Client: Ashton, Bristol
